PN020 - PIN Manager (BSI and Engine Control Unit)
Overview
PN020 - PIN Manager (BSI and Engine Control Unit)
Login for pricing
In stock
Details
The PIN Manager allows you to read the PIN code from the BSI or ECU units and use it to program keys for Peugeot and Citroen vehicles, manufactured after 2016.
Functionalities:
* PIN code reading
* Key programming (HT-AES)
* Emergency start
The PIN code is retrieved by using the ZN094 key emulator, which can consequently be used for emergency start in All Keys Lost situations, in order to start and drive the vehicle to the nearest workshop.
* For vehicles 2021+ with BSI the PIN is read directly in seconds even in a case of All Keys Lost It is no longer necessary to read the BSI EEPROM or to read the PIN from the Engine Control Unit!
* For vehicles 2022+ with VSM the PIN is read directly in seconds, but a working key is required or VSM EEPROM dump in a case of All Keys Lost.
The new procedure is a much faster, easier and safer solution!
* Note: Retrieving the PIN by ZN094 emulator does not bypass 30 minutes waiting time when learning a new key.
PN018 legacy license (now included in PN020)
The PN018 PIN Manager is a leader in the aftermarket solutions for key and remote control programming for the Peugeot/Citroën PSA vehicle range. Abrites is always one step ahead in terms of PIN code reading and key/remote control programming, covering the whole range of vehicles. PN018 lets you read the PIN code from all BSI types, and program keys, all by OBDII, as well as skip wait mode for models 2018+.
More functionalities:
* BSI Exchange - allows you to read the whole content of the one BSI and transfer it to another one. You will need to own both special function PN021 and PN020 to complete this procedure. (all BSI units)
* ECU Replacement - in case of ECU replacement, you can replace the defected ECU with a second-hand ECU, read its PIN (preferably on bench using CB013) and change the BSI PIN to match the replacement's ECU PIN. Then, a new set of keys need to be programmed to the vehicle.
The following BSI platforms are supported:
* Siemens K-Line
* Siemens CAN
* Johnson Controls CAN (including 2015+ with SPC microcontroller)
* Valeo CAN
* Continental UDS (including 2015+ locked)
* Valeo UDS
* Delphi CAN (Latin America)
* Delphi UDS
Supported models for PIN code reading:
PEUGEOT:
* 3008 II Hybrid
* Expert
* 208E
* 208 II
* 308 II
* 308 III
* 508 II
* 2008 II
* 3008 II
* 5008 II
* Partner III
SEE MORE
* 206+
* 207
* 207+
* 208
* 301
* 307 CAN
* 308
* RCZ
* 407
* 408
* 508
* 607 CAN
* 807 CAN
* 2008
* 5008
* Partner II
* Expert
* Traveller
CITROËN:
* C5 Aircross
* C3 III
* C3 Picasso
* C3 Aircross
* C4 III
* C4 Cactus
* C4 Picasso II
* C4 Aircross
* C5 Aircross
* Berlingo III
* Partner
SEE MORE
* C3 CAN
* C3 II
* C-Elysee
* C4
* C4 II
* C4 Cactus
* C4 Picasso
* C5
* C5 II
* C6
* C8 CAN
* Berlingo II
* Jumpy
* Dispatch
* Spacetour
DS:
* DS 3
* DS 3 Crossback
* DS 4
* DS 4 II
* DS 5LS
* DS 5
* DS 6
* DS 7 Crossback
Toyota:
* ProAce 2016+
Lancia:
Phedra 2008+
Opel/Vauxhall:
* Astra L
* Crossland
* Corsa F
* Combo E
* Grandland
* Mokka
* Vivaro
Fiat:
* Scudo 2022+
* Ulysse 2022+
Jeep:
* Avenger
Supported models:
* All models after 2016 with HT-AES key type
* Models equipped with a BSI module (unlocked) manufactured up to 2021
* Models equipped with a BSI module (locked) manufactured after 2021
* Models equipped with a VSM module (locked) manufactured after 2021
Examples:
* Models equipped with a BSI module, such as:
Peugeot:
* Peugeot 3008 II
* Peugeot 5008 II
* Peugeot 208 II
* Peugeot 308 II
* Peugeot 508 II
Citroën:
* Citroën C3 III
* Citroën C4 II Picasso (2016+)
* Citroën C3 Aircross
* Citroën Jumpy (2016+)
DS:
* DS 7 Crossback
* DS 3 Crossback
* Models 2021+ equipped with a VSM module, such as:
* Peugeot 308 III
* Opel Astra L
* Citroën C5 X
* DS4 II
* and many more!
