MN037 - Cluster Calibration IC177
Overview
The use of the ZN092 adapter is mandatory to ensure the safe completion of the procedure. ABRITES will not be held responsible for any technical issues or PCB damage resulting from the use of the MN037 without the ZN092 adapter.
The MN037 license allows you the unprecedented ability to calibrate IC177 clusters in Mercedes-Benz vehicles. This software license does not affect the EZS module and is much safer and easier to use. The EZS module is not even necessary when performing the procedure, all the work is done on the IC177 cluster.
Functionality:
• Adjust the mileage value in the IC177 dashboard
The procedure requires working with the IC177 module's PCB on bench, unsoldering a few capacitors and soldering the wires to the CB501 cable onto it. Wiring diagrams will be available in the software.
In order to connect to the IC177 cluster, you will need the ZN085 RH850/V850Programmer and the ZN092 adapter.
In case you encounter a module where different wiring is needed, please, submit a support ticket and we will provide additional diagrams.
AVDI with active Assist Plan is required to use this functionality.
