MN034 - DAS4 / FBS4 Personalisation Expert
Overview
The ONLY complete solution for reusing second-hand FBS4 parts or brand-new modules, not linked to vehicle / VIN! Reduce the time for getting the job done! Dealer account not needed!
MN032 or MN032F is mandatory license to purchase and use the MN034!
Login for pricing
In stock
Details
The MN034 FBS4 Personalization Expert license allows personalization of second-hand or brand-new FBS4 modules (set to virgin state) with or without available FBS4 data via OBDII and internal CAN-Bus connection. This is a major tool for working with modules from the FBS4 generation Mercedes-Benz vehicles.
Get the job done without the data from the original module!
Fast and user-friendly exchange of modules!
No dealer account needed!
Functionalities:
* Personalization of virgin second-hand modules by OBDII and internal CAN-Bus connection with or without previously saved FBS4 data from the original module
* Personalization of brand-new and unused modules by OBDII and internal CAN-Bus connection WITHOUT the need to set them to virgin state!
Disclaimer 1: FBS4 data can be read from modules and saved to file using MN032 license
NEW FUNCTIONALITY UPDATE: Personalization of virgin (brand-new or second-hand) modules when NO PREVIOUSLY SAVED PERSONALIZATION DATA FROM THE ORIGINAL MODULE IS AVAILABLE!
* MRD1/MRG1 on bench via ABRITES Distribution Box Set (ZN151) and MD1/MG1 ECU connection cable (CB030)
* MED41 (MED17.7.7) on bench via ABRITES Distribution Box Set (ZN151)
* DSM modules on bench via ABPROG
Supported modules:
Transmission Control Units: VGS-FDCT/VGS2-FDCT (7G DCT), VGS4-NAG2 (7G-Tronic), VGSNAG3 (9G-Tronic), VGS-DCT (8G FDCT)
- Personalization of virgin modules via OBDII and internal CAN-Bus connection (using FBS4 data read from the original module)
- Personalization of brand-new and unused modules via OBDII and internal CAN-Bus connection (using FBS4 data read from the orignal module)
For ALL Engine Control Units
- Personalization of virgin or brand-new modules for ALL ECU types, using FBS4 data read from the orignal module, via OBDII and internal CAN-Bus connection! (Standard personalization)
- Personalization of virgin or brand-new MED17 and EDC17 by OBDII when NO PREVIOUSLY SAVED PERSONALIZATION DATA FROM THE ORIGINAL MODULE IS AVAILABLE!
Hybrid vehicle ECUs (INV20EM01 and derivatives)
- Personalization of virgin or brand-new modules, using FBS4 data read from the orignal module, by OBD and internal CAN-Bus connection (Standard personalization)
Electric vehicle ECUs (EM01, EM02)
- Personalization of virgin or brand-new modules, using FBS4 data read from the orignal module, by OBD and internal CAN-Bus connection (Standard personalization)
DSM (all types of models) installed in vehicles equipped with VGS4-NAG2 (7G-Tronic)
- Personalization of modules, using FBS4 data read from the original module, via OBD and internal CAN-Bus connection – No need to open the module!
Required software:
MN032 DAS Manager for FBS4 vehicles
Required hardware:
AVDI – essential in order to use all ABRITES-based products and establish OBD connection
Direct CAN-BUS/LIN-BUS Connection Cable Set (CB012) – required for internal CAN-Bus connection
ABRITES Distribution Box Set (ZN151) – required for personalization of MRD1/MRG1 and MED41 (MED17.7.7) when no previously saved personalization data is available
ABPROG – required for personalization of DSM when no previously saved personalization data is available
Mercedes-Benz MD1/MG1 ECU connection cable for FBS4 Manager and ECU Programming Tool (CB030)
Extended Cable Set for all TCUs which require bench connection (CB403) – for owners of the ZN051 (older iteration of the Distribution Box Set)
Your (Assist plan) must be active in order to purchase and use the MN034 license!
