MN032 DAS Manager for FBS3/4 Cars
Overview
- W202/W208/W210
- W203/W209/W211/W219
- W168/W245
- W220/W215/R230
- W204/W207/W212/W218
- W221/W216/W251/W164/X164
- W169/W246/W117
- W166/X166
MN032 is a world leader in terms of Mercedes-Benz vehicles module replacement, key and remote programming, both for new and used control units for all vehicles up to, and including FBS3 generation.
Supported Models:
• W202/W208/W210
• W203/W209/W211/W219
• W168/W245
• W220/W215/R230
• W204/W207/W212/W218
• W221/W216/W251/W164/X164
• W169/W246/W117
• W166/X166
Module replacement
• Service password reading
• Read/Save/Update FBS Data
• Transfer FBS Data to a replacement unit
• Make each DAS/FBS module virgin, personalise and activate it
• Read/Save/Update Coding (the only way to avoid online SCN coding)
• Transfer Coding to a replacement unit
Supported Modules are all DAS related modules
• ECUs
• TCUs (7G-Tronic)
• ISM
• DSM
• ESL/EZS
• EIS/ELV
Key programming:
• Easily extract the EZS/EIS key password
• Program Infra Red keys to DAS2/DAS3 (FBS2/FBS3)
• Enable and disable key positions
Other features:
• Program the Abrites Emulators for Mercedes vehicles (EM001, EM004, EM005, EM008, EM009, EM012, EM014)
• Reset the mileage of any supported EZS/EIS.
FBS4 cars
• - Reset of FBS4 Engine control units to virgin state
• - Read the personalization data from a FBS4 ECU and saving it to a file for future use
• - Program personalization data from a previously saved file to a FBS4 ECU
• - FBS4 ECU Activation
Currently supported ECUs (produced until MY2020):
• - CR40 (EDC17C43)
• - CR41 (EDC17C66)
• - CR42 (EDC17CP46)
• - CR43 (EDC17CP60)
• - CR6 (EDC17CP10)
• - CR60 (EDC17CP46)
• - CR61 (EDC17CP57)
• - MED40 (MED17.7.1 and MED17.7.2)
• - MED177 (MED17.7.3, MED17.7.5, MED17.7.8)
• - CRD3
• - CRD3H
• - CRD3S2
• - Continental CRR1 (SID307 TC1767)
• - Continental CRR1+ (SID310 TC1791)
• - Direct connection to transmission control unit for FBS4 TCU VGSNAG3 for renewal.
• - VGS-NAG2 FBS4 Transmission control units are also supported for renewal.
• - ABPROG for FBS4 DSM Continental.
Additional and required tools:
• ZN051 Abrites Distribution Box
• ZN003 Abrites PROTAG programmer
• ZN030 Abrites ABPROG
Free for ownwers of both MN026 and MN027
